4.1 Main Web Page
The IFS Managed Switch provides a Web-based browser interface for configuring and managing it. This
interface allows you to access the Managed Switch using the Web browser of your choice. This chapter
describes how to use the Managed Switch’s Web browser interface to configure and manage it.
Figure 4-1-4: Main Page
Panel Display
The web agent displays an image of the Managed Switch’s ports. The Mode can be set to display
different information for the ports, including Link up or Link down. Clicking on the image of a port
opens the Port Statistics page.
The port states are illustrated as follows:
State Disabled Down Link
RJ-45 Ports
SFP Ports
Main Menu
Using the onboard web agent, you can define system parameters, manage and control the Managed
Switch, and all its ports, or monitor network conditions. Via the Web-Management, the administrator
Main Functions
To Next Page
