4.16.7 PD Alive-check
NS3502-8P-2S PoE switch can be configured to monitor connected PD’s status in real-time via ping
action. Once the PD stops working and without response, NS3502-8P-2S is going to restart PoE port
power, and bring the PD back to work. It will greatly enhance the reliability and reduces administrator
management burden.
This page provides you how to configure PD Alive Check. The screen in Figure 4-16-8 appears.
Figure 4-16-8: PD Alive Check Configuration screenshot
The page includes the following fields:
Object Description
• Mode
Allows user to enable or disable per port PD Alive Check function.
As default value all ports are disabled.
• Ping PD IP Address
This column allows user to set PoE device IP address here for
system making ping to the PoE device. Please be noticed that the
PD’s IP address must be set to the same network segment with
NS3502-8P-2S.
• Interval Time
(10~300s)
This column allows user to set how long system should be issue a
ping request to PD for detecting PD is alive or dead. Interval time
range is from 10 seconds to 300 seconds.
• Retry Count (1~5)
This column allows user to set how many times system retry ping to
PD. For example, if we set count 2, the meaning is that if system
retry ping to the PD and the PD doesn’t response continuously, the
PoE port will be reset.
• Action
Allows user to set which action will be apply if the PD without any
response. NS3502-8P-2S offers 3 actions as following.
PD Reboot: It means system will reset the PoE port that
connected the PD.
