SNAP: Only (SNAP) frames are allowed.
IPv4: The QCE will match only IPV4 frames.
IPv6: The QCE will match only IPV6 frames.
• Action
Indicates the classification action taken on ingress frame if
parameters configured are matched with the frame's content.
There are three action fields: Class, DPL and DSCP.
Class: Classified QoS Class; if a frame matches the QCE it will be
put in the queue.
DPL: Drop Precedence Level; if a frame matches the QCE then DP
level will set to value displayed under DPL column.
DSCP: If a frame matches the QCE then DSCP will be classified
with the value displayed under DSCP column.
• Conflict
Displays QCE status. It may happen that resources required to
add a QCE may not available, in that case it shows conflict status
as 'Yes', otherwise it is always 'No’. Please note that conflict can
be resolved by releasing the resource required by the QCE and
pressing 'Refresh' button.
Buttons
: Select the QCL status from this drop down list.
Auto-refresh : Check this box to refresh the page automatically. Automatic refresh occurs at regular
intervals.
: Click to refresh the page; any changes made locally will be undone.
4.9.13 Storm Control Configuration
Storm control for the switch is configured on this page.
There is a unicast storm rate control, multicast storm rate control, and a broadcast storm rate control.
These only affect flooded frames, i.e. frames with a (VLAN ID, DMAC) pair not present on the MAC
Address table.
The configuration indicates the permitted packet rate for unicast, multicast or broadcast traffic across
the switch. The Storm Control Configuration screen in Figure 4-9-16 appears.
