• Router Port
Specify which ports act as router ports. A router port is a port on
the Ethernet switch that leads towards the Layer 3 multicast
device or MLD querier.
If an aggregation member port is selected as a router port, the
whole aggregation will act as a router port.
• Fast Leave
Enable the fast leave on the port.
• Throtting
Enable to limit the number of multicast groups to which a switch
port can belong.
Buttons
: Click to save changes.
: Click to undo any changes made locally and revert to previously saved values.
4.8.9 MLD Snooping VLAN Configuration
Each page shows up to 99 entries from the VLAN table, default being 20, selected through the "entries
per page" input field. When first visited, the web page will show the first 20 entries from the beginning
of the VLAN Table. The first displayed will be the one with the lowest VLAN ID found in the VLAN Table.
The "VLAN" input fields allow the user to select the starting point in the VLAN Table. The MLD Snooping
VLAN Configuration screen in Figure 4-8-12 appears.
Figure 4-8-12: IGMP Snooping VLAN Configuration page screenshot
The page includes the following fields:
Object Description
• VLAN ID
The VLAN ID of the entry.
• MLD Snooping
Enable
Enable the per-VLAN MLD Snooping. Only up to 64 VLANs can be
selected.
