• Traffic Class
Indicates the Voice VLAN traffic class. All traffic on Voice VLAN
will apply this class.
• Port Mode
Indicates the Voice VLAN port mode. When the port mode isn't
disabled, we must disable MSTP feature before we enable Voice
VLAN. It can avoid the conflict of ingress filter. Possible port
modes are:
Disabled: Disjoin from Voice VLAN.
Auto: Enable auto detect mode. It detects whether there is VoIP
phone attached on the specific port and configure the Voice
VLAN members automatically.
Forced: Forced join to Voice VLAN.
• Port Security
Indicates the Voice VLAN port security mode. When the function
is enabled, all non-telephone MAC address in Voice VLAN will be
blocked 10 seconds. Possible port modes are:
Enabled: Enable Voice VLAN security mode operation.
Disabled: Disable Voice VLAN security mode operation.
• Port Discovery
Protocol
Indicates the Voice VLAN port discovery protocol. It will only
work when auto detect mode is enabled. We should enable LLDP
feature before configuring discovery protocol to "LLDP" or
"Both". Changing the discovery protocol to "OUI" or "LLDP" will
restart auto detect process? Possible discovery protocols are:
OUI: Detect telephony device by OUI address.
LLDP: Detect telephony device by LLDP.
Both: Both OUI and LLDP.
Buttons
: Click to save changes.
: Click to undo any changes made locally and revert to previously saved values.
4.9.16 Voice VLAN OUI Table
Configure VOICE VLAN OUI table on this page. The maximum entry number is 16. Modifying the OUI
table will restart auto detection of OUI process. The Voice VLAN OUI Table screen in Figure 4-9-19
appears.
