IFS NS3502-8P-2S User Manual
159
MSTI Port Configuration
Object Description
• Select MSTI
Select the bridge instance and set more detail configuration.
Figure 4-7-13: MST1 MSTI Port Configuration page screenshot
The page includes the following fields:
MSTx MSTI Port Configuration
Object Description
• Port
The switch port number of the corresponding STP CIST (and
MSTI) port.
• Path Cost
Controls the path cost incurred by the port. The Auto setting will
set the path cost as appropriate by the physical link speed, using
the 802.1D recommended values. Using the Specific setting, a
user-defined value can be entered. The path cost is used when
establishing the active topology of the network. Lower path cost
ports are chosen as forwarding ports in favor of higher path cost
