Figure 4-9-3: QoS Ingress Port Tag Classification page screenshot
The page includes the following fields:
Object Description
• Tag Classification
Controls the classification mode for tagged frames on this port.
Disabled: Use default QoS class and DP level for tagged frames.
Enabled: Use mapped versions of PCP and DEI for tagged frames.
• (PCP, DEI) to (QoS
class, DP level)
Mapping
Controls the mapping of the classified (PCP, DEI) to (QoS class, DP
level) values when Tag Classification is set to Enabled.
Buttons
: Click to save changes.
