Figure 4-12-1: Port Limit Control Configuration Overview page screenshot
The page includes the following fields:
System Configuration
Object Description
• Mode
Indicates if Limit Control is globally enabled or disabled on the
switch stack. If globally disabled, other modules may still use the
underlying functionality, but limit checks and corresponding
actions are disabled.
• Aging Enabled
If checked, secured MAC addresses are subject to aging as
discussed under Aging Period.
• Aging Period
If Aging Enabled is checked, then the aging period is controlled
with this input. If other modules are using the underlying port
security for securing MAC addresses, they may have other
requirements to the aging period. The underlying port security
will use the shorter requested aging period of all modules that
