Aging Configuration
By default, dynamic entries are removed from the MAC table after 300 seconds. This removal is also
called aging.
Object Description
• Disable Automatic
Aging
Enables/disables the automatic aging of dynamic entries
• Aging Time
The time after which a learned entry is discarded. By default,
dynamic entries are removed from the MAC after 300 seconds.
This removal is also called aging.
(Range: 10-10000000 seconds; Default: 300 seconds)
MAC Table Learning
If the learning mode for a given port is greyed out, another module is in control of the mode, so that it
cannot be changed by the user. An example of such a module is the MAC-Based Authentication under
802.1X.
Object Description
• Auto
Learning is done automatically as soon as a frame with unknown
SMAC is received.
• Disable
No learning is done.
• Secure
Only static MAC entries are learned, all other frames are
dropped.
Note: Make sure that the link used for managing the switch is
added to the Static Mac Table before changing to secure learning
mode, otherwise the management link is lost and can only be
restored by using another non-secure port or by connecting to
the switch via the serial interface.
Static MAC Table Configuration
The static entries in the MAC table are shown in this table. The static MAC table can contain 64
entries. The MAC table is sorted first by VLAN ID and then by MAC address.
Object Description
• Delete
Check to delete the entry. It will be deleted during the next save.
• VLAN ID
The VLAN ID of the entry.
• MAC Address
The MAC address of the entry.
