Figure 4-2-20: Thermal Protection Configuration page screenshot
The page includes the following fields:
Object Description
• Temperature
settings for priority
groups
The temperature at which the ports with the corresponding
priority will be turned off. Temperatures between 0 and 255 C
are supported.
• Port priorities
The priority the port belongs to. 4 priorities are supported.
Buttons
: Click to save changes.
: Click to undo any changes made locally and revert to previously saved values.
