allowed content is the ASCII characters from 33 to 126. The field
only suits to SNMPv1 and SNMPv2c. SNMPv3 is using USM for
authentication and privacy and the community string will
associated with SNMPv3 communities table.
• Write Community
Indicates the community write access string to permit access to
SNMP agent. The allowed string length is 0 to 255, and the
allowed content is the ASCII characters from 33 to 126. The field
only suits to SNMPv1 and SNMPv2c. SNMPv3 is using USM for
authentication and privacy and the community string will
associated with SNMPv3 communities table.
• Engine ID
Indicates the SNMPv3 engine ID. The string must contain an even
number between 10 and 64 hexadecimal digits, but all-zeros and
all-'F's are not allowed. Change of the Engine ID will clear all
original local users.
Configure SNMP trap on this page. The SNMP Trap Configuration screen in Figure 4-3-2 appears.
Figure 4-3-2: SNMP Trap Configuration page screenshot
The page includes the following fields:
Object Description
• Trap Mode
Indicates the SNMP trap mode operation. Possible modes are:
Enabled: Enable SNMP trap mode operation.
Disabled: Disable SNMP trap mode operation.
• Trap Version
Indicates the
