GAPS - User Guide
1. Right click on a mobile under Navigation > Equipment in the Project view panel and select
Properties in the pop-up menu that opens.
2. In the Mobile properties window, in the Source tab, select the proper geodesy.
3. Select the Symbol tab:
• Select the Style in the scrolling list. If you select User-Defined, provide the .3ds or .dxf
File.
• Select the Color in the Select color … window that opens when you click.
• Select the File that defines the style of the mobile. This option is only active when the User-
Defined Style is selected.
• You may check the Wireframe display and/or Apply vertical exaggeration options.
• In the Model Size tab, you may select the User-defined symbol size (if you chose the
User-Defined Style) or enter a value for the Width/Radius (m), Length (m) and Height (m).
• In the Offsets tab, enter the optional Offsets X, Y, Z in meters and/or degrees.
4. Select the Track Properties tab:
• Activate the Maximum number of points option if you wish to enter such a value.
• Activate the Maximum duration option if you wish to enter such a value.
• You can activate the Display vertical axis option.
• You can activate the Display range circle of radius option and input a radius.
• You can activate the Display uncertainty ellipse option.
• You can activate the LBL > Display range option and input a circular arc length.
5. Select the Pen tab:
• Select a Width in the scrolling list.
• Select a Style in the scrolling list.
• Select the Color in the Select color … window that opens when you click.
6. Select the Points tab:
• Select a Width in the scrolling list.
• Select a Style in the scrolling list.
• Select the Color in the Select color … window that opens when you click.
7. Select the Label tab, activate or not the display of the label. If you set it to Active, edit the
Font Name, Size, Bold and Italic parameters.
8. Click on the button OK to validate your choices.
The result is right away visible on the graphic display.
It is recommended to set a limitation of the track size (number of points or duration) in order to
avoid decreased performance over time.
104 MU-GAPS-AN-005-H - November 2019
