GAPS - User Guide
6.5.4 UNCERTAINTY ELLIPSE
This tool is available in real-time mode for USBL, INS and GPS data.
This tool draws an ellipse representing the confidence region for the two coordinates of a
mobile. This tools allows a quick evaluation of the uncertainty of the position of the mobile.
The tool is accessible via the button in the Equipment toolbar and via the mobile
properties window.
Figure 48 - Uncertainty ellipse
Figure 49 - Mobile properties window
110 MU-GAPS-AN-005-H - November 2019
