GAPS - User Guide
6.5.10 EVENT MARKS
This tool is available in real-time mode.
6.5.10.1 Creating an Event Mark
Click on to create an event mark. The event mark is displayed at the current location of
the selected mobile at the time when you clicked on the button. A KML file is created. This file
can contain several event marks. Another file can be created to store other marks. The mark
can be labeled (the label appears on the display), described and its width, style, color and
transparency can be edited. Date, time, position and immersion of the mark are displayed in
the Feature Data tab.
Figure 57 - Event creation window
1. During real-time display, if an event occurs and you want to create a mark to keep track of
this event, click on the button or hit [F12].
2. In Feature tab enter a Label and a Description for the mark.
3. In Label tab, set the label to Active or Inactive. Edit the Font of the label (Name, Size, Bold
or Italic).
4. In Style tab, you may choose to use a Style. In this case, select a Style in a style File to
apply to the mark.
MU-GAPS-AN-005-H - November 2019 117
