GAPS - User Guide
2.2.3.5 GAPSBox
Figure 16 - BOX front face and back face
Table 4 - Operating / Environment characteristics
Characteristics Values
Power supply / Consumption
24 to 36 VDC / 5.6 W
100-240 VAC
Weight 4.6 kg
Operating temperature -5 °C to 50 °C
Storage temperature -20 °C to + 80 °C
Highest humidity 95% at 40°C
Vibration range from 1 to 55 Hz at 1 mm / 10 m/s2
Shock acceleration 15 m/s2 for 15 ms, ½ sinus
32 MU-GAPS-AN-005-H - November 2019
