5.3 Setting Up the Transponders
GAPS tracks iXblue transponders and transponders using Sonardyne Wideband® 1 signals
(option). Interrogation and reply signals are given below. Contact iXblue for more information.
Table 11 - iXblue Transponders compatible with GAPS
MT8
F1, F2, F3 & F4
19.5 – 21, 0.5 kHz steps
MFSK 22 - 23
MT9
F1, F2, F3 & F4
19.5 – 21, 0.5 kHz
MFSK 22 - 23
MFSK 00 - 09
ET/RTAx2
19.5 – 30.5, 0.5 kHz
MFSK 22 – 23, 0 – 45
19.5 – 30.5, 0.5 kHz
MFSK 22 – 23, 0 – 45
ZTA02C
MFSK 0 – 44,
45 telemetry
MFSK 0 – 44,
45 telemetry
RAMSES
19.5 – 30.5, 0.5 kHz
MFSK 22 – 23, 0 – 35
MFSK 22 – 23, 0 – 35
STAx2 MFSK 21.5 - 30.5 kHz MFSK 21.5 - 30.5 kHz
CANOPUS
CW 19 to 32.5 kHz
MFSK22, 23, 0 to 45
CHORUS, telemetry
CW 19 to 32.5 kHz
MFSK22, 23, 0 to 45
CHORUS, telemetry
MTB
CW 19 to 32.5 kHz
MFSK22, 23, 0 to 45
CHORUS, telemetry
CW 19 to 32.5 kHz
MFSK22, 23, 0 to 45
CHORUS, telemetry
MU-GAPS-AN-005-H - November 2019 83
