GAPS - User Guide
9.3.1.2 NAVIGATION Window
On the navigation window are displayed the following data:
● Navigation data: Heading and attitude (Heading, Roll, Pitch), Position (UTM Zone, UTM
North, UTM East, Depth, Speed), Heave (Heave, Surge, Sway), Time (Run Time, UTC
Time), Acoustics (Tracking, Noise Lev., Noise lvl H1, Noise lvl H2, Noise lvl H3, Noise
lvl H4), GPS (Attitude, Mode, Std. Dev, Time)
● Positioned transponder data:
Data Definition
Latitude
Geographic coordinates of the transponder
Longitude
Depth Depth computed with acoustic data and optional external sensors data
Sensor depth Depth provided by optional external sensors
X Rel. Antenna
Transponder coordinates with respect to the frame centered on the
antenna and to the antenna axes
Y Rel. Antenna
X Rel. North
Transponder coordinates with respect to the frame centered on the
antenna and to the geographical axes
Y Rel. North
Slant Range Traveled distance
H. Distance Horizontal distance
Bearing
Transponder angle seen from the antenna with respect to the along
track axe of the ship
Azimuth Transponder angle seen from the antenna with respect to the North
Vertical Angle Transponder angle seen from the antenna with respect to the vertical
SNR, SNR H1,
SNR H2, SNR H3,
SNR H4
Signal to noise ratio global and specific to each hydrophone
Travel Time Travel time of the acoustic wave to reach the transponder
146 MU-GAPS-AN-005-H - November 2019
