GAPS - User Guide
6. In Symbol tab:
● Select the Style in its scrolling list. For User-Defined, provide the .3ds file.
● Select the Color in the Select color … window that opens when you click.
● Select the File to define the style of the mobile. This option is only active when the User-
Defined Style is selected.
● You may check the Wireframe display and Apply Vertical exaggeration options.
● In Model Size tab, enter a Length (m), Width/Radius (m) and the Height (m) values.
● In Offsets tab, enter the optional Offsets X, Y, Z in meters and/or degrees.
7. In Points tab:
● Select a Width in the scrolling list.
● Select a Style in the scrolling list.
● Select the Color in the Select color … window that opens when you click.
8. Open the Display properties tab and move the cursor along the Transparency scale to
choose a value between 0 and 100%.
9. Click on the button OK to validate your choices.
The waypoint is created and displayed on the mouse cursor position. A data file and an
waypoint are added to the Annotations/Features/Waypoints folder in the Project view panel.
