GAPS - User Guide
Hoisting Sys. UP Antenna stored in service chest
Hoisting Sys. DOWN Antenna deployed
Gate Valve CLOSED Gate valve closed
Gate Valve OPEN Gate valve opened
Hoisting Sys. Fault Hoisting System out of service
ANTENNA:
Transponder Int. The system is not triggered. Check that the synchro is sent to the rack.
Data Sampling
Internal problem coming from the signal
processing module.
Switch off the rack and turn it on again. If
the problem remains, contact iXblue.
Maximum Range
One or several detections are close to
the end of the acquisition period.
Increase the interrogation rate.
Channel 1/2/3/4 detection
The system does not detect the signal
coming from the transponder on the
channel 1, 2, 3 or 4.
If message appears for a short time, it may
be due to external environment. If problem
remains continuously, there might be a
problem with the antenna or with the
antenna cable. Contact iXblue.
Channel 1/2/3/4 NIS Error
Error occurred on one of the four chan-
nels 1, 2, 3 or 4. 5 dB detected between
two channels.
Hydrophone broken or a lot of noise detec-
ted by one hydrophone.
Speed Limit (12 kt)
Ship sails too fast, antenna mechanical
limit might be reached.
Reduce speed.
Stacking Init Discovery mode for the ping stacking
Stacking Ping stacking mode active
TRANSPONDERS:
Expected Transponders that are expected in the next interrogation.
No Detection Less than 3 hydrophones providing data.
No Position Impossible to compute a position.
Pressure Received Data collected from pressure sensor.
Pressure Used Pressure data required by transponder and used.
Antenna not calibrated The antenna is not calibrated.
Simulated Detections The delivered positions are coming from simulated detections.
Ping Navigation No navigation at interrogation time.
Detected Navigation No navigation at detection time.
1 Disabled Hydro. One hydro is deactivated.
BOX:
No GAPS BOX Cannot find the GAPS BOX
Network Configuration Network configuration error
Serial A/B/C/D Configuration Serial input error
Ethernet A/B/C/D Configuration Ethernet input error
150 MU-GAPS-AN-005-H - November 2019
