GAPS - User Guide
I.5 DATA LEGACY
BB
XXXXX X
YYYYY Y
A
PPPP
A
CCCC
Transponder No. or ship’s No. 0: Ship 01 to 15: Transponder
coordinates m
coordinates m
Position validity (XYZ) 0 to F: binary coding of acoustic
Depth BUC in meters
Depth validity 0: none 1: BUC 2: Sensor
Sensor depth m
Example:
$PTSAX,01,00100,00199,F,0301,1,9999*16
$PTSAX,01,00100,00199,F,0301,1,9999*16
$PTSAX,04,-0010,00004,F,1135,1,9999*0F
$PTSAX,04,-0010,00004,F,1135,1,9999*0F
I.6 DATA PTSAG
The DATAPTSAG protocol is derived fromDATASTANDARD protocol. DATAPTSAG
includes only the PTSAGmessage (see section I.4.1) only with transponder information
(IDfield = 1 to 128).
