GAPS - User Guide
Antenna characteristics (theoretical and measured)
Description Format Unit Observation
Header
Synchronization
Total Size
Datagram ID
Datagram release number
byte
byte
byte
byte
'$'
102
$83
$01
Theoritical
antenna
Pair H1 / H2
Delta X
Delta Y
Delta Z
Delta Phase
float
float
float
float
meter
meter
meter
radian
RANT o H1
RANT o H1
RANT o H1
Pair H2 / H3
Delta X
Delta Y
Delta Z
Delta Phase
float
float
float
float
meter
meter
meter
radian
RANT o H2
RANT o H2
RANT o H2
Pair H3 / H4
Delta X
Delta Y
Delta Z
Delta Phase
float
float
float
float
meter
meter
meter
radian
RANT o H3
RANT o H3
RANT o H3
Measured
antenna
Pair H1 / H2
Delta X
Delta Y
Delta Z
Delta Phase
float
float
float
float
meter
meter
meter
radian
RANT o H1
RANT o H1
RANT o H1
Pair H2 / H3
Delta X
Delta Y
Delta Z
Delta Phase
float
float
float
float
meter
meter
meter
radian
RANT o H2
RANT o H2
RANT o H2
Pair H3 / H4
Delta X
Delta Y
Delta Z
Delta Phase
float
float
float
float
meter
meter
meter
radian
RANT o H3
RANT o H3
RANT o H3
Checksum ushort
