450 Keysight N9010A EXA Service Guide
Replaceable Parts
Hardware
Figure 14-31 Chassis
Item Description Keysight Part Number
MP1 Chassis Base Refer to Table 14-1
MP2 Chassis Side, Right (inner) Refer to Table 14-1
MP3 Chassis Side, Left (inner) Refer to Table 14-1
MP4 Midplane Bracket W1312-00048
MP5 Chassis Front Bracket Refer to Table 14-1
MP6 Fan Bracket Refer to Table 14-1
MP8 Chassis Side, Right (Outer, attaches to Lowband Switch bracket,
Attenuator brackets, and Chassis bottom)
Refer to Table 14-1
MP9 Rear Panel Replacement Kit (includes foam strip) Refer to Table 14-1
MP36-37 Attenuator Bracket Refer to Table 14-1
