Program
P0
P1 P2 P3 P4 P5 P7 P8 P9
19
Time:
Attack (Attack Time) [00…99]
Specify the time over which the volume will change after
note-on until it reaches the attack level.
If the start level is 0, this will be the rise time of the sound.
Decay (Decay Time) [00…99]
Specify the time over which the volume will change from
when it reaches the attack level until it reaches the break
point level.
Slope (Slope Time) [00…99]
Specify the time over which the volume will change from
when it reaches the break point level until it reaches the sus-
tain level.
Release (Release Time) [00…99]
Specify the time over which the volume will change after
note-off until it reaches 0.
4–3b: Level Modulation
These parameters let you use an alternate modulation
source to modify the amp 1 EG levels that were specified in
“Amp 1 EG” (4–3a).
AMS (Alternate Modulation Source) [Off, (KT, EXT)]
Select the source that will control the “Level” parameters of
the amp 1 EG (
☞p.210 “AMS (Alternate Modulation Source)
List”).
Intensity [–99…+99]
Specify the depth and direction of the effect that “AMS” will
have.
For example if “AMS” is Velocity, setting “St,” “At,” and
“Br” to + and setting “Intensity” to a positive (+) value will
cause the amp 1 EG volume levels to increase as you play
more strongly. Setting “Intensity” to a negative (–) values
will cause the amp 1 EG volume levels to decrease as you
play more strongly. With a setting of 0, the levels will be as
specified in “Amp 1 EG” (4–3a).
St (Start Level) [–, 0, +]
Specify the direction in which “AMS” will change “Start
(Start Level).” If “Intensity” is set to a positive (+) value, set-
ting this parameter to + will allow AMS to increase the EG
level, and setting this parameter to – will allow AMS to
decrease the EG level. With a setting of 0, no change will
occur.
At (Attack Level) [–, 0, +]
Specify the direction in which “AMS” will change “Attack
(Attack Level).” If “Intensity” is set to a positive (+) value,
setting this parameter to + will allow AMS to increase the
EG level, and setting this parameter to – will allow AMS to
decrease the EG level. With a setting of 0, no change will
occur.
Br (Break Point Level) [–, 0, +]
Specify the direction in which “AMS” will change “Break
(Break Point Level).” If “Intensity” is set to a positive (+)
value, setting this parameter to + will allow AMS to increase
the EG level, and setting this parameter to – will allow AMS
to decrease the EG level. With a setting of 0, no change will
occur.
4–3c: Time Modulation
These parameters let you use an alternate modulation
source to modify the amp 1 EG times that were specified in
“Amp 1 EG” (4–3a).
AMS1 (Alternate Modulation Source 1) [Off, (EXT, KT)]
Select the source that will control the “Time” parameters of
the amp 1 EG (
☞p.210 “AMS (Alternate Modulation Source)
List”).
With a setting of Off, there will be no modulation.
Intensity (AMS1 Intensity) [–99…+99]
Specify the depth and direction of the effect that “AMS1”
will have.
For example if “AMS1” is Amp KTrk +/+, the (Amp) Key-
board Track settings (4–2a) will control the EG “Time”
parameters. With positive (+) values of this parameter, posi-
tive (+) values of “Ramp (Ramp Setting) will cause EG times
to be lengthened, and negative (–) values of “Ramp (Ramp
Setting)” will cause EG times to be shortened. The direction
of the change is specified by “At,” “Dc,” “Sl,” and “Rl.”
When “AMS1” is Velocity, positive (+) values will cause EG
times to lengthen as you play more strongly, and negative (–)
values will cause EG times to shorten as you play more
strongly. With a setting of 0, the EG times will be as specified
in “Amp1 EG” (4–3a).
At (Attack Time) [–, 0, +]
Specify the direction of the effect that “AMS1” will have on
“Attack (Attack Time).” With positive (+) values of “Inten-
sity,” setting this parameter to + will allow AMS1 to
lengthen the time, and setting it to – will allow AMS1 to
shorten the time. With a setting of 0 there will be no effect.
Dc (Decay Time) [–, 0, +]
Specify the direction of the effect that “AMS1” will have on
“Decay (Decay Time).” With positive (+) values of “Inten-
sity,” setting this parameter to + will allow AMS1 to
lengthen the time, and setting it to – will allow AMS1 to
shorten the time. With a setting of 0 there will be no effect.
Sl (Slope Time) [–, 0, +]
Specify the direction of the effect that “AMS1” will have on
“Slope (Slope Time).” With positive (+) values of “Inten-
sity,” setting this parameter to + will allow AMS1 to
lengthen the time, and setting it to – will allow AMS1 to
shorten the time. With a setting of 0 there will be no effect.
Note-on
Note-off
Attack
Time
Decay
Time
Release Time
Attack Level
Sustain
Level
Time
Break Point
Start
Level
Slope
Time
Amplifier EG
Volume
Amp 1 EG changes (Level) (AMS=Velocity, Intensity = a positive (+) value)
Note-on
Note-off
Note-on
Note-off
Note-on
Note-off
Softly played note when St=0
and At and Br are set to +
(settings of 4–3a: Amp 1 EG)
Strongly played note
when St=0 and At and Br
are set to +
Strongly played note
when St=0 and At and Br
are set to –
