Leightronix MINI-T-NET - Saving Controller Image Files

NET Series
Software Operation
LEIGHTRONIX, INC. Firmware Ver. 1.00.42/Software Ver. 1.0.2.6 Page 109
2010-07-09
 If you wish to record while a signal is transmitting on-air, select the on-air
output on the NET-164 or the NET-EC’s switcher.
 NET-164 and NET-EC only—if you wish to record and display video on a
monitor, select the monitor output on the NET-164 or the NET-EC’s
switcher.
b. Select day/date of event.
c. Select time of event.
d. Set length of event.
e. Set preroll, if desired.
f. Select “Record” in “Command” field.
3. Schedule a playback device action by dragging desired playback device icon onto
playlist. In the “Event Properties” window that appears, perform the following:
a. In the “Output” field, select the NET-164 or NET-EC’s switcher output
connected to your recording device.
b. Select day/date of event.
c. Select time of event.
d. Set length of event.
e. Set preroll, if desired.
f. Select “Play” in “Command” field.
SAVING CONTROLLER IMAGE FILES
Save your Controller image files to reuse the device and media resource icons with or
without the playlist of events during future scheduling.
 “Save” Option
If a loaded Controller image has been modified, or not saved locally in the case
of a received or a new image file, the “Save” option becomes enabled. Select
“Save” from the “File” menu or by clicking its icon.
 If the Controller image already has a local name, visible in the title bar
(WinNET – image.cmg), “Save” saves the loaded image to that name
without prompting, overwriting the old file.
 If the image does not have a name, “Save” opens the “Save as” box shown
in Illustration 74, “Save As” Window, allowing a name and folder to be
specified.
 “Save as” Option
The “Save as” option allows you to save the loaded Controller image under a
new name and, if desired, a template filter of your choosing. Select “Save as” in
