NET Series
Controller Installation and Configuration
Page 26 Firmware Ver. 1.00.42/Software Ver. 1.0.2.6 LEIGHTRONIX, INC.
2010-07-09
CONFIGURING FRONT PANEL SETTINGS
NOTE: All crucial configuration information, such as user information, schedule
information, time, and network information, are stored in battery backed or
flash memory. Thus the NET Series Controller configuration is protected in
the instance of an extended power failure.
ENTERING PASSWORD
1. Press the right arrow key from any one of the status screens to display the
password entry screen (see Illustration 12, NET Series Password Entry Screen).
Illustration 12, NET Series Password Entry Screen
2. Press the five-key password.
NOTE: The factory-default password is five right arrow keys. To change
password, see “Changing Front Panel Password,” on page 53.
3. If the password is correctly entered, the NET Series Controller’s main menu will be
displayed (see Illustration 13, NET Series Main Menu Screen). If the password is
incorrectly entered, the display returns to the status screens.
Illustration 13, NET Series Main Menu Screen
Use arrow keys to enter
Password:*****
MAIN MENU Use `/ˆ
Setup ~
