NET Series
Controller Installation & Configuration
LEIGHTRONIX, INC. Firmware Ver. 1.00.42/Software Ver. 1.0.2.6 Page 31
2010-07-09
SETTING COM 1 BAUD RATE FOR MINI-T-NET AND NET-164
NOTE: The “COM 1” port is reserved for use with any product that has its own
software for controlling the MINI-T-NET or NET-164.
Use to set the MINI-T-NET and the NET-164 Controller’s serial port baud rate within a
range of 115200 to 1200 baud. The baud rate must be programmed from the
Controller’s front panel (see Table 6, Configuring Serial Port Baud Rate from Front
Panel).
Table 6, Configuring Serial Port Baud Rate from Front Panel
SERIAL COMMUNICATIONS
CONFIGURATION STEPS
CORRESPONDING SCREEN DISPLAYS
1. From the “MAIN MENU” screen, press “↑” or
“↓” to proceed to “Setup.”
2. Press “→” to select “Setup.”
3. Press “↑” or “↓” to proceed to “Set COM 1
Baud Rate.”
4. Press “→” to select “Set COM 1 Baud Rate.”
5. Press “↑↓” to change com 1 baud rate.
6. Press “→” to enter next screen.
7. Either press “→” again to save your changes
or “←” to abort changes.
EDITING IP ADDRESS
Obtain IP address from your technical support personnel or network administrator.
See Table 7, Editing IP Address from Front Panel, for editing instructions.
Table 7, Editing IP Address from Front Panel
IP ADDRESS CONFIGURATION STEPS CORRESPONDING SCREEN DISPLAYS
1. From the “MAIN MENU” screen, press “↑” or “↓”
to proceed to “TCP/IP Configuration.”
2. Press “→” to select “TCP/IP Configuration.”
3. Press “↑” or “↓” to proceed to “Edit IP Address.”
4. Press “→” to select “Edit IP Address.”
IP CONFIG MENU Use `/ˆ
Edit IP Address ~
MAIN MENU Use `/ˆ
TCP/IP Configuration ~
Press ~ to set baud rate
115200 baud
Set COM 1 Baud Rate
115200
baud
SETUP MENU Use `/ˆ
Set COM 1 Baud Rate
~
MAIN MENU Use `/ˆ
Setup
~
