NET Series
Front Panel Operation
Page 124 Firmware Ver. 1.00.42/Software Ver. 1.0.2.6 LEIGHTRONIX, INC.
2010-07-09
VIEWING STATUS SCREENS
After the Controller has been booted up, press the up or down arrows on the
Controller’s keypad to display the following status screens:
SWITCHER STATUS/TYPE
MINI-T-NET: the bottom line of the screen shows the switcher status (see
Illustration 89, MINI-T-NET Switcher Status Screen). The number is the input
number (the output number is not indicated as there is only one output). The
triangle indicates the valid video status on the output (solid =valid video,
hollow=lack of valid video).
Illustration 89, MINI-T-NET Switcher Status Screen
NET-164: the bottom line of the screen shows the switcher status (see
Illustration 90, NET-164 Switcher Status Screen). The first number in each pair
is the input number and the second is the output number. The triangle indicates
the valid video status on the output (solid =valid video, hollow=lack of valid
video).
Illustration 90, NET-164 Switcher Status Screen
NET-EC: the bottom line of the screen indicates the switcher type that has been
set and the NET-EC’s serial communication status (see Illustration 91, NET-EC
Switcher Type and Serial Communication Status Screen).
Illustration 91, NET-EC Switcher Type and Serial Communication Status Screen
Thu Jul 31 12:00:00 PM
Switcher: 4$ Menu~
Wed Oct 10 12:00:00PM
3@1 4$2 5$3 5$4 ~
Wed Oct 10 12:00:00PM
SW=PESA Com=OK Menu~
