NET Series
Front Panel Operation
Page 128 Firmware Ver. 1.00.42/Software Ver. 1.0.2.6 LEIGHTRONIX, INC.
2010-07-09
 Input number
 - (none—only MINI-T-NET)
 Switch Output (only NET-164 or NET-EC)
NOTES:
 The MINI-T-NET does not have a switch output field, as it is a
single channel switcher.
 The NET-164 allows up to four switches for a single force,
allowing the user to take the same input to any combination or
all four outputs.
 The NET-EC allows the entry of an output number from 1 to
the configured maximum or none, but only one switch per
forced event.
Illustration 102, NET-164 Example: Switch Output Number Selected
 Output number
 - (none)
 Switch Delay Time
Illustration 103, NET-164 Example: Switch Delay Time Selected
Force: Dev. 1 Play
Switch 1$- 2 3 4 in –s
Force: Dev. 1 Play
Switch 1$- 2 3 4 in 3s
