NET Series
Software Installation and Configuration
LEIGHTRONIX, INC. Firmware Ver. 1.00.42/Software Ver. 1.0.2.6 Page 71
2010-07-09
Output aliases
1. Enter the external switch’s first and last output values into the “First”
and “Last” output fields. Each of the inputs in this range may be
assigned an alias.
2. Type an alias into the “Name” field of the selected output (up to 31
characters).
Playlist channel output assignments
A NET-EC playlist can have up to 8 channels, represented by tabs on the
left side of the playlist window. In the “Channel” field, select a channel and
assign an output to the channel in the “Output” field.
External switch type, size, levels, and status rate
NOTE: The switch type, size, and levels may also be set from the
Controller’s front panel.
1. “Switch type” field: select your external switcher type. The choices are:
LEIGHTRONIX PRO-8 or PRO-16, Pesa CPULink, Sigma, Sierra, and
Knox.
2. “Levels” field: use to enter the number of levels (video, audio left, audio
right, etc.) configured on the external switch.
NOTE: Consult your switcher manual to determine how many levels
should be assigned.
3. “Status rate (sec)” field use to configure the interval at which the NET-
EC polls the external switcher for output status information. The range
is 0 – 6000 milliseconds, where 0 means never poll. The default is
2000 milliseconds.
