NET Series

Software Operation

LEIGHTRONIX, INC. Firmware Ver. 1.00.42/Software Ver. 1.0.2.6 Page 97

2010-07-09

Table 16, Editable PRO-BUS-Controlled Device Event Fields

FIELD DESCRIPTION

Lock Box At the top is a checkbox for locking or unlocking the event. A locked event’s

time is fixed and can be edited. Checking this box enables the “Time” field.

Name Allows a name of up to 31 characters to be entered.

Device Allows a different device of the same format to be chosen. Its associated

input will appear in the “Input” field.

Comment Allows up to 31 characters to be entered.

Time If the event is locked, the event “Time” can be modified. This is the

scheduled “On-Air“ time of the event.

Event Start

Command

Can be chosen from the following commands: “Play,” “Stop,” “Rewind,” and

“Record.” It will almost always be “Play.”

Preroll Enter as needed. Indicates amount of video at start of a program that you

do not want playing on air.

Length This must be entered to indicate the duration of the event.

Reset time Enter as needed. Only implemented if the end command is “Rewind.”

Indicates how long a playback device will be busy and unavailable for

scheduling after the end of a program.

Event End

Command

Can be chosen from the following commands: “Play,” “Stop,” “Rewind,” and

“Record.” It will usually be “Rewind” or “Stop.” For DVD, check your

interface manual and switches to determine the actions performed by the

“Rewind” and “Stop” commands. By default, “Rewind” does a DVD full stop

(back to beginning), and “Stop” stops the DVD at the current location.

Fallback input Used to enter the input to be taken to the output at the end of the event.

Media ID Assign as a library tracking number.

Field Name

1–x

Playlist column headings you may assign.

Print Select “Yes” to enable record for printing. If “No” is selected, then the

record can only be printed by checking the “Export/print all records” option
