Chapter 5 – Parameter list
5-17
CODE
Comm.
Addr
Description
LCD Keypad
Display
Setting Range
Factory
Default
Adj.
During
Run
Page
APP-61
973D
Decel time when the number
of pump increases
Pid DecTime 0 to 600.0 [sec] 2.0 [sec] O 6-65
APP-62
973E
PID Bypass Selection Regul Bypass
0 (No)
1 (Yes)
0 (No) X 6-65
APP-63
973F
Sleep Delay Time Sleep Delay 0.0 to 9999 [sec] 60.0 [sec] O 6-66
APP-64
9740
Sleep Frequency Sleep Freq 0 to FU1-30 [Hz] 0.00 [Hz] O 6-66
APP-65
9741
Wake-Up Level WakeUp level 0.0 to 100.0 [%] 2.0[%] O 6-66
APP-66
9742
Auto Change Mode Selection AutoCh_Mode 0, 1 (Aux), 2 (Main) 0 O 6-67
APP-67
9743
Auto Change Time AutoEx-intv 00:00 to 99:00 72:00 O 6-67
APP-68
9744
Auto Change Level
AutoEx-level
FU1-32 to
FU1-30 [Hz]
20.0 [Hz]
O 6-67
APP-69
9745
Inter-Lock Selection
Inter-lock
0 (No)
1 (Yes)
0 (No) O 6-68
APP-71
9747
Pressure difference for Aux
motor Stop
Actual Pr Diff 0 to100%
2% O 6-70
APP-74
974A
PrePID Reference Frequency PrePID freq 0 to FU1-30 0.00 [Hz] O
APP-75
974B
PrePID Exit Level PrePID Exit 0 to 100.0% 0.0 [%] O
APP-76
974C
PrePID Stop delay PrePID dly 0 to 9999 600 [sec] O
6-70
APP-80
9750
Ext PID Operation Selection Ext PI mode
0 (No)
1 (Yes)
0 (No) X 6-70
APP-81
(30)
9751
Ext PID Reference
Signal Selection
Ext Ref Sel
0 (I)
1 (V1)
2 (Pulse)
3 (Key-Pad)
3 (Key-Pad) X 6-70
APP-82
9752
Ext PID
Reference Level
Ext Ref Perc 0 to 100.00 [%] 50.00 [%] X 6-70
APP-83
9753
Ext PID Feedback Signal
Selection
Ext Fbk Sel
0 (I)
1 (V1)
2 (Pulse)
0 (I) X 6-70
APP-85
9755
P Gain for ExtPID ExtPID Pgain 0 to 999.9 [%] 1.0 [%]
X 6-70
APP-86
9756
I Time for ExtPID ExtPID Itime 0 to 32.0 [sec] 10.0 [sec]
X 6-70
APP-87
9757
D Time for ExtPID ExtPID Dtime 0 to 2000 [msec] 0 [msec]
X 6-70
APP-88
9758
High Limit Frequency for
ExtPID Control
ExtPID lmt-H
0 to 100.00 [%]
100.00 [%]
X 6-70
APP-89
9759
Low Limit Frequency for
ExtPID Control
ExtPID lmt-L
0 to 30.00 [%]
0.00 [%]
X 6-70
APP-90
975A
ExtPID Output Scale
ExtPID Scale 0 to 999.9 100.0 [%]
X 6-70
APP-91
975B
ExtPID P2 Gain
Ext P2-gain 0 to 999.9 100.0 [%]
X 6-70
APP-92
975C
ExtPID
P Gain Scale
Ext P Scale
0 to 100.0
100.0 [%]
X 6-70
APP-93
975D ExtPID F Gain ExtPID F-gain 0 to 999.9 [%] 0.0 [%] O 6-70
