Mariner 80 - Fuel Line and Primer Bulb Assembly

3A-2990-13645--2 495 FUEL SYSTEM AND CARBURETION
Fuel Line and Primer Bulb Assembly
a
b
c
d
e
f
g
h
i
j
k
l
m
n
i
a - Fuel Line Assembly
b - Primer Bulb Assembly
c - Check Valve, Inlet
d - Fittng, Outlet
e - Clamp, Primer Bulb to Check Valve (Large)
f - Clamp, Fuel Line to Check Valve (Small)
g - Connector, Fuel Tank (Outlet)
h - Connector, Engine (Inlet)
i - Clamp, Fuel Line to Connector
j - Bayonet Body Assembly (Fuel Tank End)
k - Stem, Bayonet Body
l - O-ring, Bayonet Body Stem
m- Spring, Bayonet Body Stem
n - Washer, Cupped - Body Spring
