6C-1790-13645--2 495 POWER-TRIM
Troubleshooting the “Down” Circuit*
(When “Up” Circuit is OK)
*Remote Control Not Equipped with Trailer Button
Battery Voltage Indicated:
Down Relay is Defective. Replace
and retest.
No Voltage Indicated:
Connect Voltmeter red lead to Point 4 and
black lead to ground. Depress “Down” trim
button. If battery voltage is indicated, wire
is open between Points 4 and 1.
No Voltage Indicated:
Connect Voltmeter red lead to Point 5. If battery volt-
age is indicated, trim switch is faulty. If no battery
voltage, check for loose or corroded connection at
Point 5 or open circuit in wire supplying current to
Point 5.
Connect Voltmeter red lead to Point 1
and black lead to ground.
Depress the “Down” trim button.
Troubleshooting the “Up” Circuit*
(When “Down” Circuit Is OK)
*Remote Control NOT Equipped with Trailer Button
Battery Voltage Indicated:
UP Relay is defective. Replace
and retest.
No Voltage Indicated:
Connect Voltmeter red lead to Point 7 and
black lead to ground. Depress “Down”
trim button. If battery voltage is indicated,
wire is open between Points 7 and 8.
No Voltage Indicated:
Connect Voltmeter red lead to Point 5. If battery voltage is
indicated, trim switch is faulty. If no battery voltage, check
for loose or corroded connection at Point 5 or open circuit
in wire supplying current to Point 5.
Connect Voltmeter red lead to Point 8
and black lead to ground.
Depress the “Up” trim button.
To Next Page
