Mariner 80 - Flywheel Installation; Intake Manifold - Torque Sequence

4A-3790-13645--2 495 POWERHEAD
Flywheel Installation
1. Reinstall Flywheel, washer and nut.
2. Torque Flywheel Nut to 120 lb. ft. (162.7 Nm).
20344
3. Reinstall Reed Block Housings, Intake Manifolds,
and Flywheel Cover Bracket.
INTAKE
MANIFOLD
GASKET
INSTALL
INTAKE MANIFOLD
AS ONE UNIT
REED BLOCK
ASSEMBLY
19574
INTAKE MANIFOLD - TORQUE SEQUENCE
4
2
1
3
5
4. Torque each intake manifold, in sequence, to 18 lb.
ft. (24.4 Nm).
NOTE: Flywheel Cover Bracket uses longer bolts.
5. Install Carburetor Gaskets.
6. Reinstall Carburetors as Single-Unit Assembly.
Note manifold hose position and connection.
19094
a
a - Manifold Hose
7. Reconnect main fuel line hose, and fuel enrich-
ment hose. Secure fuel line “a” with sta-strap.
8. Reconnect throttle linkage.
19093
a
b
c
a - Main Fuel Hose
b - Fuel Enrichment Hose
c - Throttle Linkage
