4A-30 90-13645--2 395POWERHEAD
S Install 2 ring seals into slot between each center
main bearing and position ring seal end gaps 180_
apart.
51083
RING SEAL
2 Each Center
Main
Any GREASE used for bearings INSIDE the
Powerhead MUST BE gasoline soluble. Use only
Quicksilver Needle Bearing Assembly Lubricant
(92-42649A-1) or 2-4-C w/Teflon (92-825407A12). If
other lubricants are used inside the Powerhead,
damage to engine may occur.
CAUTION
Grease crankshaft journal with Needle Bearing As-
sembly Lubricant, to hold bearings in place. Position
bearings on journal, 32 each center main bearing.
20046
Attach bearing races with holes toward lower gear
end of crankshaft. Secure each main bearing race
with retaining ring.
20040
ab
c
a - Main Bearing Race
b - Retaining Ring
c - Top Main Bearing
To install top main bearing, lubricate needle bearing
with light oil, and slide bearing assembly, (holes
toward lower end), onto shaft.
20040
