5A-390-13645--2 1095 LOWER UNIT
Drive Shaft and Water Pump Components (Continued)
TORQUE
REF. NO. QUAN. DESCRIPTION lb. in. lb. ft. N⋅m
1 1 Drive Shaft (Long)
Drive Shaft (X-Long)
2 1 Shim
3 1 Bearing Race
4 1 Tapered Bearing
5 1 Washer
6 1 Screw 60 6.8
7 1 Washer
8 1 Screw 60 6.8
9 1 Washer
10 1 Screw (Magnetic) 60 6.8
11 1 Pinion Nut 70 94.9
12 1 Pinion Gear
13 1 Shift Cam (Letters Face Up)
14 1 Trim Tab
15 1 Washer
16 1 Trim Tab Bolt 22 29.8
17 1 Oiler Tube
18 1 Carrier
19 1 Needle Bearing (Numbers Face Up)
20 1 Gasket (Not used with nylon cover assy.)
21 1 Oil Seal (Lip Up)
22 1 Oil Seal (Lip Down)
23 1 Cover Assembly
24 1 Gasket
25 1 Face Plate
26 1 Gasket
