5A-590-13645--2 1095 LOWER UNIT
Drive Shaft and Water Pump Components (Continued)
TORQUE
REF. NO. QUAN. DESCRIPTION lb. in. lb. ft. N⋅m
27 1 Impeller Drive Key
28 1 Impeller
29 1 Water Pump Assembly
30 1 Water Tube Seal
31 4 Water Pump Bolt 60 6.8
32 Delete
33 Delete
34 6 Cover Screw 60 6.8
35 Delete
36 1 Wear Sleeve
37 1 Seal Ring
38 2 Bushing Screw 35 3.9
39 1 Oil Seal (Lip Up)
40 1 Shift Shaft Bushing
41 1 O-Ring
42 1 Shift Shaft “E” Ring
43 1 Shift Shaft (Long)
1
Shift Shaft (X-Long)
44 1 Gear Housing
45 1 Shift Shaft Adapter
46 1 Reverse Lock Cam
47 1 Washer
To Next Page
