Mariner 80 - Page 176

5A-790-13645--2 1095 LOWER UNIT
Propeller Shaft Components (Continued)
TORQUE
REF. NO. QUAN. DESCRIPTION lb. in. lb. ft. N⋅m
1 1 Gear Case
2 1 Shim
3 1 Bearing Race
4 1 Tapered Roller Bearing
5 1 Roller Bearing
6 1 Forward Gear
7 1 Cam Follower
8 3 Ball Bearing
9 1 Slide Cross Pin
10 1 Spring
11 1 Clutch
12 1 Clutch Cross Pin
13 1 Retainer Spring
14 1 Propeller Shaft
15 1 Reverse Gear
16 1 O-Ring
17 1 Thrust Bearing
18 1 Thrust Washer
19 1 Roller Bearing
20 1 Bearing Carrier
21 1 Washer
22 1 Nut (Design 2) or Bolt (Design 1) 260 21.7 29.4
23 1 Roller Bearing
24 1 Oil Seal (Lip In)
25 1 Oil Seal (Lip Out)
26 1 Thrust Washer
27 1 Propeller
28 1 Tab Washer
29 1 Propeller Nut 55 75
30 2 Stud
