5B-390-13645--2 495 LOWER UNIT
Swivel Bracket Components (Continued)
TORQUE
REF. NO. QUAN. DESCRIPTION lb. in. lb. ft. N·m
1 1 Swivel Bracket
2 1 Oil Seal (LIPS FACE DOWN)
3 2 Bushing
4 1 O-Ring (UPPER)
5 1 Spacer (UPPER)
6 2 Grease Fitting 40 4.5
7 2 Bushing
8 1 Swivel Pin and Steering Arm Assembly
9 2 Bolt
10 2 Rubber Mount (UPPER)
11 2 Washer
12 2 Washer
13 2 Nut 80 108.4
14 1 Steering Link Assembly
15 1 Bolt – 1-1/4 in. (31.7mm) Long
16 1 Lock Nut 20 27.1
17 1 Lock Nut 120 13.5
18 2 Washer
19 1 Wave Washer
20 1 Bottom Yoke
21 1 Retaining Ring
22 1 Thrust Washer (ALUMINUM SIDE TOWARDS SWIVEL BRACKET)
23 1 Bumper
To Next Page
