5B-990-13645--2 495 LOWER UNIT
Drive Shaft Housing Components (Continued)
TORQUE
REF. NO. QUAN. DESCRIPTION lb. in. lb. ft. N·m
1 1 Drive Shaft Housing
2 1 Drive Shaft Housing Stud
3 2 Dowel Pin
4 4 Gear Housing Stud
5 5 Washer
6 5 Nut 40 54.5
7 1 Plug – Power Trim
8 1 Speedometer Pick Up Assembly
9 1 90 Degree Connector
10 1 Straight Connector
11 2 Lower Mount
12 2 Lower Mount Bolt
13 2 Washer (CHAMFER SIDE TOWARDS MOUNT)
14 2 Washer
15 2 Washer
16 2 Nut 50 67.8
17 1 Ground Strap
18 1 Ground Strap Bolt
19 2 Lower Mount Clamp
20 4 Nylon Nut
21 4 Clamp Bolt 13.8 18.7
22 2 Lower Mount, Cover
23 4 Cover Screws Drive Tight
NON POWER TRIM
24 1 Reverse Lock Hook
25 1 Push Rod
26 1 Shaft
27 1 Cotter Pin
28 2 Bushing
29 1 Spring
30 1 Cotter Pin
31 1 Washer
32 1 Push Rod Spring
33 1 Push Rod Yoke
34 1 Nut
35 1 Clevis Pin
36 1 Cotter Pin
To Next Page
