Mariner 80 - Page 249

6A-2590-13645--2 495 POWER TRIM
Power Trim Components (Continued)
TORQUE
REF. NO. DESCRIPTION lb. in. lb. ft. N⋅m
16 Tilt Cylinder Assembly
17 Cross Pin
18 Retaining Pin
19 Pin
D20 O-ring [1.248I (31.70mm) I.D.]
21 Trim Rod Assembly w/Check Valve, Port
D22 O-ring [.612I (15.54mm) I.D.]
D23 O-ring [1.475I (37.47mm) I.D.]
24 Cap, Trim Cylinder
D25 Seal
D26 O-ring (2.864I I.D.)
27 Washer
28 Bolt
29 Reservoir Cover
D30 O-ring [.583I (14.81mm) I.D.]
31 Fill Screw
JD32 O-ring [2.739I (69.57mm) I.D.]
(If Equipped)
33 “Square” Motor Assembly
34 Square Ring, used when end frame cap
has groove
35 Gasket, used when end frame cap does
NOT have groove
36 Bolt 70 7.9
37 Allen Bolt 70 7.9
38 Lockwasher
39 End Frame Cap
40 O-ring (or Flat Ring)
J41 O-ring [2.739I (69.57mm) I.D.]
J42 O-ring [2.614I (66.40mm) I.D.]
J43 Flat Ring
44 Pump Assembly
45 Screen (If Equipped)
46 Washer (If Equipped)
47 Screw (If Equipped)
J Contents of “Pump Seal Kit” (P/N 12663)
D Contents of “Power Trim O-ring Kit” (P/N 25-48462A1)
* It is recommended O-ring be installed even if pump was not originally equipped with this O-ring.
