90-13645--2 1095 6B-3POWER TRIM
Power Trim Components (Continued)
TORQUE
REF. NO. QUAN. DESCRIPTION lb. in. lb. ft. N⋅m
1 1 Manifold
2 9 Pipe Plug
3 1 Tilt Cylinder Assembly
4 1 Piston Rod (Bolt Type) Design 1
5 1 Piston Rod (Nut Type) Design 2
6 1 Guide Kit
7 1 O-ring Repair Kit (811607A1)
8 1 Check Valve Kit
9 1 Guide Assembly
10 1 Piston and Rod Assembly (Port)
10 1 Piston and Rod Assembly (Starboard)
11 1 Trim Filter Assembly
12 1 Groove Pin
13 1 Valve Assembly
14 1 E-ring
15 4 Screw
16 4 Washer
17 1 Cover
18 1 O-ring Kit (811612A1)
19 1 Plug Assembly
20 1 Shaft Assembly
21 2 Plug Pipe
22 1 Trim Motor
23
2
Screw (Long) 70 7.9
23 2 Screw (Short) 70 7.9
24 1 Pump
25 1 Driveshaft
26 1 Shaft
27 1 Anode Assembly
28 2 Screw 60 6.8
29 2 Washer
30 2 Striker Plate
31 2 Lockwasher
32 2 Nut 80 9.0
33 1 Groove Pin
34 1 Control Harness, Power Trim
35 1 Cable (6-3/8″ – Red)
35 1 Cable (24″ – Red)
35 1 Cable (2-3/4″ – Red)
36 2 Clip, Pump Wire
37 2 C-Washer, Clip Screw
38 2 Screw, Clip to Transom Bracket
39 6 Screw, Manifold 30 40.7
40 6 Flatwasher, Manifold Screw
To Next Page
