6C-590-13645--2 495 POWER-TRIM
Power Trim System Components (Continued)
TORQUE
REF. NO. QUAN. DESCRIPTION lb. in. lb. ft. N⋅m
1 1 Tilt/Trim Cylinder
2 1 Reservoir/Motor Housing
3 1 Piston Rod
4 1 Upper Pivot Shaft
5 1 Cross Pin
6 1 O-ring
7 1 Seal-End Cap
8 1 End Cap
9 1 O-ring
10 1 O-ring
11 1 Piston Assembly 35 4.0
12 1 O-ring
13 1 O-ring
14 1 Memory Piston
15 1 Lower Pivot Shaft
16 1 Cross Pin
17 2 Screw 100 11.3
18 1 Pump Assembly
19 1 Pilot Valve Assembly
20 1 O-ring
21 1 Driveshaft
22 4 Washer
23 4 Screw 70 7.9
24 1 Fill Screw
25 1 O-ring
26 1 Motor Frame
27 2 Thrust Washer
28 1 Armature
29 1 Ring
30 1 Seal
31 2 Screw 13 1.5
32 4 Screw 13 1.5
33 2 Relay
34 1 Wiring Harness
35 2 Relay Mount
36 2 Rubber Mount
37 2 Screw 35 4.0
38 2 Spacer
39 1 Anode
40 2 Washer
41 2 Screw 70 8.0
42 1 Manual Release Valve
43 3 O-rings
44 1 E-Clip
