7B-590-13645--2 495 OUTBOARD MOTOR INSTALLATION/ATTACHMENTS
Tiller Arm Bracket Assembly (Continued)
TORQUE
REF. NO. QUAN. DESCRIPTION lb. in. lb. ft. N⋅m
1 1 Bracket Assembly
2 2 Stud
3 1 Spacer
4 2 Tab Washer
5 2 Nut 35 47.4
6 1 Grommet
7 1 Harness Assembly
8 1 Key Switch
9 1 Nut
10 1 Cover
11 6 Screw Drive Tight
12 1 Plug
13 1 Stop Switch Assembly
14 1 Lanyard
15 1 Retainer
16 1 Bolt 110 12.4
17 3 Tab Washer
18 2 Bushing
19 1 Shift Lever
20 1 Washer
21 1 Stud
22 1 Shift Knob
23 1 Shift Rod
24 1 Rod End
25 1 Bushing
26 1 Washer
27 1 Cotter Pin
28 1 Neutral Start Switch
29 1 Bracket
30 1 Switch Bracket
31 2 Screw
32 2 Nut Drive Tight
33 2 Bolt
34 2 Washer
35 2 Nut Drive Tight
36 2 Bolt 15 20.3
37 1 Detent Assembly
38 1 Trim Switch
39 1 Nut
