1-2 90-13645--2 1095GENERAL INFORMATION AND SPECIFICATIONS
General Specification
(continued)
NOTE:
Other specification (torques, etc.) are listed in
the respective sections.
Model 100 Model 115
Horsepower 100 (74.6 kw) 115 (85.8 kw)
Idle RPM (in forward gear) 650 - 700
Full Throttle RPM Range 4750 - 5250
Piston Replacement 105 (1720.9cc)
Cylinder Bore 3.375 (85.7mm)
Stroke 2.930 (74.4mm)
Engine Type 4 Cylinder, 2 Cycle
Ignition Type C.D. Breakerless
Recommended Spark Plug
NGK-BPH8H-N-10* Gap - 0.040 in. (1.0mm)
Inductor Plug NGK BPZ 8H-N-10* Gap - 0.040 in. (1.0mm)
NGK-BUHW
Cylinder Firing Order 1-3-2-4
Recommended Power Trim Fluid
Quicksilver Power Trim & Steering Fluid or Automotive Transmission
Fluid (ATF) Type F, FA or Dexron II
Recommended Gasoline
Regular Leaded, Premium, Low-Lead and Lead-Free automotive gaso-
lines with a minimum pump posted octane rating of 86
Recommended Oil Quicksilver 2-Cycle Outboard Oil
Engine Weight ELO
ELOPT
340 lbs.
360 lbs.
Fuel Tank Capacity
6.6 U.S. Gallons
(5 Imp. Gals.; 25 Liters)
Gear Housing Lubricant Capacity 22.5 fl. oz. (665.2ml)
Gasoline/Oil Ratio at Idle 80:1
Gasoline/Oil Ratio at W.O.T. 50:1
Gear Ratio 2.07:1
Oil Injection Tank Capacity
Tank Capacity 1.4 gal. (5.3 liters)
Maximum operation per tank
full of oil at W.O.T.
5 hours
Oil remaining when warning
buzzer sounds
1 qt. (.95 liter)
Operating time remaining at
wide open throttle when warn-
ing buzzer sounds
50 min. approx.
*Improves running quality between 1800 – 2000 RPM.
