Midas PRO2 User Manual

182 Chapter 21: Scope (Automation)
PRO2 Live Audio System
Owner’s Manual
Selecting bus parameters
As a channel’s bus parameter section represents all of its available buses collectively,
you can only select either all or none of its buses using the scope function buttons.
However, by clicking the bus parameter section you can open its ‘bus select’ window,
which lets you select any buses you want out of scene. In this window each aux/matrix
bus is represented by an single icon, and only available buses are shown.
Typical ‘bus select’ window
The background colour of the bus parameter for each channel shows the selection
status of its respective buses. There are three states, as shown in the following table.
>> To select/deselect buses
In the ‘bus select’ window, do one of the following:
• To select/deselect a single bus, click on its icon.
• To select/deselect all buses, click All.
Bus selection status Symbol
None of the buses are selected
One or more, but not all, of the buses
are selected
All of the buses are selected
Type and number of
currently selected bus
All 24 buses
Currently selected bus
(green background)
Unselected bus (blue
background)
Click All to select/
deselect all buses

Midas PRO2 Specifications

General

Sample Rate	96 kHz
Talkback	Yes
MIDI I/O	Yes
Computer Connectivity	USB, Ethernet
Processing	40-bit floating point
Recallable Preamps	Yes
Channels	64
Matrix	8 matrix buses
Display	15" TFT display
Connectivity	Ethernet, MIDI
Type	Digital
EQ Bands	4-band parametric EQ
Inputs - Mic Preamps	8 XLR
Outputs - Main	8 XLR
Effects	Reverb, Delay, Modulation, etc.
Dynamic Processing	Gate, Compressor, Limiter
Control Surface	Motorized faders, touchscreen
Power Supply	Internal
