Midas PRO2 User Manual

Typical configurations 223
PRO2 Live Audio System
Owner’s Manual
Monitor Mix
The following table shows the delay compensation settings for this mix.
The following example signal paths all measure the same latency of 300 samples @
96kHz = 3.125 ms:
• FOH XLR – IP – MAST – XLR
• XLR – IP – MAST – XLR
• XLR – IP – MTX – XLR
• XLR – IP – MAST- MTX – XLR
• XLR – IP – AS – XLR
• XLR – IP – AS (With GEQ) – XLR
• XLR – AS DI – AS – XLR
• XLR – AS DI – AS (With GEQ) – XLR
• XLR – AR (Input) – MAST – XLR
• XLR – AR (Input) – MAST (With GEQ) – XLR
• XLR – AR (Input) – MTX (With GEQ) – XLR
• XLR – AR (Input) – MAST - MTX - XLR
• XLR – AR (Input) – MAST - MTX (With GEQ) - XLR
Option On/off status
Master to Matrix Post-processing Off
Input Channels
Insert Off
Aux Sends
Monitor Mode (Align with Masters)
Insert
Send-FX-Return
Graphic EQ
On
On
Off
On
Master and Matrix
Insert
Graphic EQ
On
On

Midas PRO2 Specifications

General

Sample Rate	96 kHz
Talkback	Yes
MIDI I/O	Yes
Computer Connectivity	USB, Ethernet
Processing	40-bit floating point
Recallable Preamps	Yes
Channels	64
Matrix	8 matrix buses
Display	15" TFT display
Connectivity	Ethernet, MIDI
Type	Digital
EQ Bands	4-band parametric EQ
Inputs - Mic Preamps	8 XLR
Outputs - Main	8 XLR
Effects	Reverb, Delay, Modulation, etc.
Dynamic Processing	Gate, Compressor, Limiter
Control Surface	Motorized faders, touchscreen
Power Supply	Internal
