Midas PRO2

Rear panel connections 231
PRO2 Live Audio System
Owner’s Manual
AES3
The AES3 section has two pairs of input and output connectors for synchronisation
with external devices that can transmit/receive a 96kHz AES3 signal.
Talk back
The talk back input connector accepts a female input XLR.
AES50 audio
Six AES50, 24-wide, bi-directional digital audio EtherCon® ports.
out 3 & 4
in 3 & 4 out 1 & 2
in 1 & 2
