8-15
 [AG Comp]: enters the concentration of anesthetic gas (if there is) in the ventilation gas
mixture to compensate for the effect of anesthetic gas upon the readings.
The total of the concentrations of O2 compensation and AG compensation cannot be greater
than 100%.
8.5.2.4 Set Maximum Hold
In the CO2 parameter area, EtCO2 and FiCO2 values are refreshed in real-time. To set
EtCO2 and FiCO2:
1. Access the [Gas Module Setup >>] menu.
2. Select [Max Hold] and select:
 [Single Breath]: EtCO
2
and FiCO
2
are calculated based on each breath.
 [10 s]and [20 s]: EtCO
2
and FiCO2 refer to the highest and the lowest CO2 values
measured respectively within the configured time period (10 s or 20 s).
8.5.2.5 Restore Defaults
Select [Defaults] from the [Gas Module Setup >>] menu. Then all the menu options except
[Working Mode] are restored to the factory default configurations.
8.5.2.6 Set CO2 Waveform
1. Select the waveform area to access the waveform setup menu.
2. Select [Waveform] and select [CO2].
3. Select [Sweep] and set waveform sweep speed to an appropriate value. The greater the
value is, the faster the waveform sweeps, the wider the waveform is.
4. Select [Scale] and toggle between:
 [40], [60] and [80] if the unit is mmHg;
 [5.0], [7.5] and [10.0] if the unit is % or kPa.
5. Select
to exit the current menu.
For details about displaying the CO2 waveform, refer to 5.3.3.2Display CO2 Waveform.
