C
ONFIGURING SOFTKEYS PAGING KEY
Configuring a Phone Lock Key
1. Click on Operation > Softkeys and XML.orClick on Operation > Expansion Module <N>.
Softkeys
2. Select from Key 1 through Key 48 on the Top keys.orSelect from Key 1 through Key 30 on the Bottom
keys.
3. In the Type field, select Phone Lock from the list of options.
Expansion Module Keys
4. Select from Key 1 through Key 84(M695).
5. In the Type field, select Phone Lock from the list of options.
6. Click Save Settings.
NOTE: You can lock/unlock the phone using the new key you just configured, using the Mitel Web UI
at the path Operation > Phone Lock, or using the Phone Lock option on the IP phone UI at the path
Options > Lock > Phone Lock. For more information about using the lock/unlock feature, see
“Locking the Phone Using the IP Phone UI” on page 76 .
Paging Key
You can configure a Paging key on the phone that allows you to send a Real Time Transport Protocol
(RTP) stream to pre-configured multicast address(es) without involving SIP signaling. You enter a multi-
cast IP address(es) and a port number for the Paging key, that when pressed, initiates an outgoing multi-
cast RTP session. This is called Group Paging on the IP phones.
You can also specify group paging RTP addresses that the phone listens for when receiving RTP
streams. You can specify up to 5 listening multicast addresses at the path, Basic Settings > Preferences
> Group Paging RTP Settings.
For more information about Group Paging and how it works, and to specify multicast addresses, see
“Group RTP Paging” on page 219.
